Flat Black Cables
Stealthy and flexible, the fixed flat black cables are easy to maneuver for cable management while also taking up less space in your system.
Main Power Connector 24 (20+4)Pin x1
X1
EPS 12V Connector 8 (4+4)Pin x1
X1
PCI-E (6+2)Pin x2
X1
SATA x3 + 4Pin Peripheral x1
X2
Technical Spec
| Type | ATX12V V2.4 |
| Product Dimensions | 150×140×86mm (W x L x H) |
| 80PLUS Certifications | 230V EU White |
| Fan Size | 120mm |
| Fan Bearing | Hypro Bearing |
| Topology | Active PFC+Double tube forward |
| Capacitors | Taiwan bulk capacitor |
| Power Good Signal | 100-500ms |
| Hold Up Time | ≥16ms(75% Load) |
| Efficiency | ≥85% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP |
| Operation Temperature | 0-40°C |
| Regulatory | CB/CCC/CE/UKCA/EAC/RCM |
| Erp Regulation | ErP 2010 |
| MTBF | 100,000 Hours |
| EAN P/N | 6933412702177 R-PF400D-HA0B-AU 6933412702184 R-PF400D-HA0B-AR 6933412702191 R-PF400D-HA0B-CN 6933412702207 R-PF400D-HA0B-EU 6933412709282 R-PF400D-HA0B-UK 6933412709299 R-PF400D-HA0B-WO 6933412709305 R-PF400D-HA0B-BP 6933412711650 R-PF400D-HA0B-US |
