Technical Spec
| Type | ATX12V V3.1 |
| Product Dimensions | 150×140×86mm (W x L x H) |
| Efficiency certification | 80Plus Bronze/Cybenetics Silver/PPLP Silver/CQC II 级 |
| Fan Size | 120mm |
| Fan Bearing | HYB(Hydro Bearing) |
| Topology | Active PFC+DC to DC |
| Capacitors | Chinese Electrolytic Capacitors |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms |
| Efficiency | ≥85% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0 – 40℃ |
| Regulatory | CE/FCC/CCC/RCM/EAC/ CAN ICES-003(B)/NMB-003(B) /TUV-RH |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman/P65 |
| MTBF | 100,000 Hours |
| EAN P/N | 6933412721505 R-PL800D-FC0B-CN-V2 6933412721512 R-PL800D-FC0B-AU-V2 6933412721529 R-PL800D-FC0B-EU-V2 6933412721536 R-PL800D-FC0B-JP-V2 6933412721543 R-PL800D-FC0B-UK-V2 6933412721550 R-PL800D-FC0B-US-V2 6933412721567 R-PL800D-FC0B-IN-V2 6933412721574 R-PL800D-FC0B-WO-V2 6933412721581 R-PL800D-FC0B-BP-V2 |
