ModelMPE-7501-AFAAG-3
ATX VersionATX 12V Ver. 3.0
PFCActive PFC
Input Voltage100-240V
Input Current10-5A
Input Frequency50-60Hz
Dimensions (L x W x H)160 x 150 x 86 mm
Fan Size120mm
Fan BearingHDB
Efficiency≥90% @ Typical Load
80 PLUS Rating80 PLUS Gold
ErP 2014 Lot 3Yes
Operating Temperature0-50°C
Power Good Signal100 – 150 ms
Hold Up Time≥ 16ms
MTBF>100,000 Hours
ProtectionsUVP / OVP / OPP / OTP / SCP / OCP
RegulatoryTUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI, BIS, UKCA
ATX 24 Pin Connectors1
EPS 4+4 Pin Connectors1
EPS 8 Pin Connector1
SATA Connectors12
Peripheral 4 Pin Connectors4
PCI-e 6+2 Pin Connectors4
12VHPWR Connector1 (1 to 3)
CategoryAbove 750W
SeriesMWE Gold Series
ModularFully Modular
Form FactorATX
80 Plus EfficiencyGold
Watts750W
