COOLERMASTER G GOLD 750 V2 FULL

General Specifications

• Model: MPE-7502-ACAAG
• ATX Version: ATX 12V Ver. 3.1
• PFC: Active PFC
• Input Voltage: 100-240V
• Input Current: 10-6A
• Input Frequency: 50-60Hz
• Dimensions (L x W x H): 140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
• Fan Size: 120mm
• Fan Bearing: HDB (Hydro Dynamic Bearing)
• Efficiency: ≥90% @ Typical Load
• 80 PLUS Rating: 80 PLUS Gold
• ErP 2014 Lot 3: Yes
• Operating Temperature: 0-40°C
• Power Good Signal: 100 – 150 ms
• Hold Up Time: >16ms
• MTBF: >100,000 Hours
• Protections: UVP / OVP / OPP / OTP / SCP / OCP
• Regulatory: cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region’s requests.)

Connectors

• ATX 24 Pin Connectors: 1
• EPS 8 Pin / 4+4 Pin Connectors: 2
• SATA Connectors: 6
• Peripheral 4 Pin Connectors: 3
• PCI-e 6+2 Pin Connectors: 4

Additional Information

• Series: G Series
• Category: 500 to 750W
• Modular: Non Modular
• 80 Plus Efficiency: Gold
• Form Factor: ATX
• Watts: 750W
